Exxelia has released a set of new Micropen white papers with practical insights for printed electronics in medical and sensor designs that go into real design details for printed electronics on medical devices, radiopaque markers, analytical instrumentation and integrated sensors.
For engineers and technical purchasers working with high‑reliability passive and sensing functions, these Exxelia documents can help clarify when Micropen direct‑write technology is a viable alternative to conventional wired components and assemblies.
What Micropen technology offers to hardware designers
Micropen is a direct‑write printed electronics process that deposits functional materials (for example resistive, conductive or sensing inks) directly onto a substrate instead of using separate chips, wires or assemblies according to the manufacturer’s documentation. This enables resistors, heaters, sensors and interconnects to be formed as patterns on complex 2D or 3D geometries, including medical device surfaces and structures in analytical instruments.
For designers used to conventional thick‑film or SMD passives, the key value is the ability to “turn the substrate into the component” by integrating these functions in place, rather than routing to remote discrete parts. This can reduce interconnect count, shorten signal paths and simplify mechanical packaging in tight or dynamic spaces such as catheters, probes or compact analyzers.
Key themes of the new Micropen white papers
The new white papers from Exxelia Micropen focus on several application domains around printed electronics and sensor integration:
- Printed electronics on medical devices, including ways to embed sensing or heating functionality directly onto device surfaces according to manufacturer documentation. Exxelia Micropen – Printed Electronics on Medical Devices white paper
- Direct‑written radiopaque markers for medical devices, positioned as an alternative to traditional marker bands and coils. Exxelia Micropen – Radiopaque (RO) marker white paper
- Micropen‑fabricated drift tubes for mass spectrometry and ion mobility spectrometry in analytical instruments. Exxelia Micropen – Drift tubes for mass spectrometry and ion mobility spectrometry white paper
- A journal‑style biomedical technology and research article related to technological integration in clinical environments. Journal of Biomedical Technology and Research
- Design concepts for replacing wired sensors, resistors, heaters and antennas with direct‑printed structures. Revolutionizing Design and Sensors; Design Idea – Replace Wired Sensors and Resistors
Together, they form a technical overview of how direct‑write printing can replace, complement or extend classical passive components and interconnects in demanding applications.
Typical applications highlighted in the Micropen material
The specific white papers linked from the Micropen technical center cover scenarios where passive or sensor functionality is directly printed onto or into a mechanical structure. Typical use cases include:
- Medical devices
- Printed sensors and heaters on catheters, probes or surgical instruments for temperature monitoring, ablation control or therapy delivery.
- Conductive patterns and resistors printed on implantable or temporary devices where space and biocompatibility are critical (exact examples and limits are detailed in the white papers and datasheets).
- Radiopaque markers printed as patterns on device surfaces, offering an alternative to metal bands or coils for X‑ray visualization while minimizing added profile and avoiding sharp transitions.
- Analytical instrumentation
- Drift tubes for mass spectrometry and ion mobility spectrometry with printed resistive or electrode structures along the tube wall, enabling controlled electric fields and compact assembly.
- Integration of printed heater or sensor elements onto structural parts, reducing the need for separate heater cartridges or bolted‑on sensors.
- General sensor and passive integration
- Replacement of wired sensors and discrete resistors used for temperature, position, or pressure monitoring by printed resistor and sensor patterns.
- Printed antennas or RF structures integrated on dielectric supports or housings, depending on material compatibility and frequency requirements as detailed in the relevant design documentation.
In many of these cases, Micropen functionality plays a similar role to traditional thick‑film resistors, heaters or sensor elements, but applied directly to the final substrate instead of an intermediate ceramic or PCB.
Design‑in notes for engineers
When evaluating Micropen‑based solutions as part of a passive or sensor design strategy, consider the following practical points:
- Treat the printed function like a custom passive
- Rather than selecting a catalog SMD resistor or thermistor, you are effectively specifying a custom printed element whose geometry, resistance, layout and location can be tuned for your application.
- Early engagement with Exxelia’s technical team and the relevant Micropen white papers is recommended to define electrical ratings, environmental limits and mechanical constraints according to manufacturer datasheets.
- Understand thermal paths and power density
- For printed heaters or power resistors on thin‑wall catheters, probes or drift tubes, the thermal path into the surrounding medium (fluid, tissue, gas) is critical.
- Use the white papers as a starting point, then perform your own simulation or testing to validate power density, temperature gradients and maximum allowable operating temperatures according to your safety case.
- Define insulation and creepage/clearance
- Where printed conductors or resistors are used at elevated voltages, creepage and clearance distances along the substrate surface must be designed according to IEC and UL requirements for your equipment class.
- Surface finish, coatings, humidity exposure and pollution degree all influence how close printed features can be without risking tracking or breakdown.
- Specify measurement and test requirements
- For sensor applications (temperature, pressure, position, flow), define calibration strategy, drift limits and test conditions in your component or subassembly specification.
- Micropen’s ability to produce consistent geometries should help with repeatability, but your test plan needs to confirm performance over the full lifetime and environmental range.
- Consider supply chain and lifecycle
- Since Micropen is a process‑driven technology, the “component” is a combination of substrate, ink and printing process carried out by Exxelia.
- Purchasing and engineering teams should align on long‑term availability, change control, and second‑source strategies (if any) as they would with other custom or application‑specific passive components.
Availability and how to access the white papers
The new Micropen white papers are available through the Exxelia Technical Center under the Micropen‑related guides and technical documents section. From the overview page, engineers can navigate directly to individual titles such as printed electronics on medical devices, radiopaque markers, drift tubes for mass spectrometry and the design idea paper on replacing wired components with direct‑printed structures.
Source
This article is based on information published by Exxelia in its Micropen guides and technical center materials, with interpretation and context added for design and purchasing engineers. For detailed ratings, performance data and application limitations, always refer to the original white papers and associated datasheets from the manufacturer.
