Power Electronics Tools for Passives and Magnetic Designs

Modern power electronics design relies on a diverse toolbox, from general‑purpose circuit simulators to highly specialized magnetics and component‑selection platforms. Understanding the role and limitations of these tools is essential when specifying passive components such as inductors, transformers, capacitors, and resistors in a cost‑sensitive, time‑critical design flow.

This article is based on edited newsletter article by Dr.Molina, Frenetic CEO.

From topology to real components

Power converter development typically follows a workflow: requirements gathering, specification, topology selection, simulation, component design/selection, and finally schematic capture and PCB layout. The tools reviewed in this article sit mainly in the topology evaluation, circuit simulation, and component design/selection stages, where they strongly influence passive component sizing, stress margins, and BOM structure.

A key takeaway is that no single environment covers everything from first‑principles magnetics design to detailed PCB‑level parasitics and full BOM optimization. Instead, design teams usually combine several tools: one or more simulators for behavior and losses, parametric selectors from major semiconductor manufacturers, and specialized magnetics design suites for custom inductors and transformers.

Key categories of tools

General‑purpose circuit simulators

These are SPICE‑class environments used heavily for SMPS and analog design, often forming the “backbone” of a lab’s simulation flow.​

• LTspice (Analog Devices) is a widely adopted, free desktop simulator used for switching power supplies and analog circuits. It offers strong convergence, a large ecosystem of models, and community support, but has limited integration with PCB and component management tools and a dated user interface.
• PSpice/OrCAD‑class environments provide more extensive enterprise workflows, combining schematic, PCB, and BOM management with powerful simulation features at a higher licensing cost and complexity.

For passive components, these tools are typically used to verify voltage and current waveforms across inductors, transformers, capacitors, and resistors, evaluate losses, and check stability margins before hardware builds.

Power‑electronics‑focused simulators

Some simulators are optimized specifically for SMPS and converter behavior, trading transistor‑level detail for speed and robustness in switching applications.

• PSIM (Siemens, originally Powersim) is a long‑standing power‑electronics‑focused circuit simulator, widely used in both industry and education. It is noted for very easy use, fast convergence in switching converters, and suitability for rapid topology evaluation, but has less detailed device‑level models than SPICE.
• PLECS focuses strongly on control‑loop design and system‑level modeling of power converters. It is not intended for device‑level transistor simulation but excels at power stage plus control interaction and is often coupled with external magnetics tools.
• SIMPLIS is positioned as a converter design and verification platform, integrating switching power supply simulation with time‑domain efficiency and strong control features. It emphasizes schematics that closely resemble real SMPS circuits and very fast convergence, with licensing based on an initial fee plus annual updates.

For passive components, these platforms help determine worst‑case stress, verify soft‑switching or hard‑switching regimes in inductors and transformers, and validate the interaction between magnetics, capacitors, and control loops before committing to a custom core or winding strategy.

Parametric selectors from manufacturers

Most semiconductor and magnetics manufacturers offer online parametric tools for device selection, covering power MOSFETs, diodes, inductors, and sometimes transformers.

These web‑based tools allow engineers to filter components by voltage rating, current, core material, saturation limits, package, DC resistance, and other key parameters. They are particularly helpful at the early selection stage, ensuring that candidate passives meet headline electrical and thermal constraints before detailed simulation and layout.

However, parametric selectors are typically vendor‑specific, limited to that supplier’s catalog, and rarely integrate deeply with schematic, simulation, or PCB environments. They are best treated as a starting point for a longlist of feasible parts, which are then refined using more detailed simulation and magnetics design tools.

Online calculators

Online calculators—such as core sizing tools, loss estimators, and basic inductor/transformer calculators—remain widely used, especially by younger engineers or for quick cross‑checks.

They help validate first‑order design equations and offer sanity checks on core size, turns count, and current density. Their main limitation is isolation from the wider design flow: they usually do not “know” about the actual waveforms, duty cycles, or control strategy in the real converter, so their results must be validated in a full simulator.

Simulators and their role for passives.

Tool	Type	Main purpose in passives work	Typical use in flow
LTspice	General‑purpose SPICE simulator	Waveform‑level validation of stress on inductors, caps, resistors	Concept validation, detailed circuit analysis
PSIM	Power‑electronics‑focused simulator	Fast topology evaluation, converter‑level loss and stress analysis	Architecture selection, education, early design
PLECS	Power‑electronics/system simulator	Control‑loop and system‑level interaction with magnetics and caps	Control design, system studies
SIMPLIS	Converter design and verification	SMPS behavior, time‑domain efficiency, magnetics plus control checks	Design verification before hardware

Specialized magnetics design tools

Legacy but proven: RidleyWorks

RidleyWorks is a long‑standing power supply design and analysis package with a strong following among SMPS designers. It spans topology selection, loop analysis, and magnetics design, using an Excel‑based interface with macros for data entry and calculations.

• Strengths: Mature models, particularly for control‑loop estimation; solid reputation in the community; used in real industrial environments.
• Limitations: Many models are based on the historical work of the tool’s author, while magnetics modeling techniques and materials have evolved significantly in the last two decades; project storage is rudimentary, often requiring screenshots or manual archiving.

For passive components, RidleyWorks is valuable for loop‑stability analysis, compensation design, and power stage parameterization, which indirectly drives capacitor ESR and inductor/transformer design targets.

High‑fidelity physics: COMSOL and similar FEA

Finite‑element tools such as COMSOL (mentioned in the article series) are typically used as the “physics validation” stage once a baseline design exists. They are particularly relevant when:

• Winding arrangements and leakage inductance must be tightly controlled.
• Core losses and hot spots need 3D evaluation.
• Very high efficiency, high power density, or unusual core shapes are required.

In a passive component context, FEA tools are best reserved for critical or custom magnetics where traditional lumped‑parameter models are insufficient, due to cost, setup effort, and required expertise.

Workflow‑centric tools: SIMPLIS with Magnetics Design Module

Beyond pure simulation, platforms like SIMPLIS extend into magnetics sizing through dedicated modules. Its Magnetics Design Module (MDM) and Design Verification Module (DVM) allow engineers to design and size inductors and transformers in the context of the full converter, rather than as standalone calculations.

This workflow checks operating points, stresses, waveforms, and margins against design rules, effectively answering whether the design works—not just what the waveforms look like. For passive components, this is a major step toward “model‑based” magnetics design integrated with system‑level performance.

Cloud‑based magnetics design: Frenetic

Frenetic is an online tool for designing and simulating transformers and inductors, with a workflow centered on cloud‑based projects and collaboration.

• It provides topology‑based templates and lets users define constraints (power, frequency, size, thermal limits) to synthesize magnetics that meet those targets.
• Designs are stored in the cloud under defined security standards, enabling team access and versioning.

For passive component engineers, Frenetic’s main value lies in accelerating custom magnetics design, exploring multiple core and winding configurations, and converging quickly on manufacturable solutions that meet specified losses and temperature rise limits.

Magnetics‑focused tools

Tool	Focus area	Typical passive decisions supported	When to prefer it
RidleyWorks	SMPS design and loop analysis	Inductor and transformer sizing linked to control stability	When loop design and legacy workflows matter
COMSOL	3D physics / FEA	Detailed core/copper loss and hot‑spot analysis	When operating near physical limits
SIMPLIS MDM	Integrated magnetics design	Core selection, turns, winding layout in full‑circuit context	When converter and magnetics are tightly coupled
Frenetic	Cloud magnetics synthesis	Core selection, window use, thermal and loss trade‑offs	When fast custom magnetics iterations are needed

Typical applications and tool fit

Different stages of a power converter design call for different tool capabilities, particularly when passive components dominate cost, volume, and reliability.

• PFC stages and DC link: Power‑electronics‑focused simulators (PSIM, PLECS, SIMPLIS) and SPICE tools (LTspice) are commonly used to size boost inductors, DC‑link capacitors, and EMI filters, by checking current ripple, harmonic content, and stress under line/load extremes.
• Isolated DC/DC converters: Magnetics design tools (RidleyWorks, Frenetic, SIMPLIS MDM) help design transformers and output inductors to meet isolation and efficiency targets, while general simulators validate control loop stability and transient behavior.
• Automotive ECUs and industrial drives: Tight EMI and thermal constraints make parametric selectors and detailed magnetics tools essential, as designers must combine catalog filters, physics‑based evaluation, and system‑level simulation to meet safety and reliability standards.
• Chargers and adapters: High volume and aggressive cost targets favor workflows where parametric selectors, online calculators, and fast simulators are used to rapidly iterate magnetics and capacitor options, with FEA reserved only for reference or flagship designs.

Example: workflow versus passive decisions.

Design stage	Representative tools	Main passive‑related decisions
Topology exploration	LTspice, PSIM, PLECS, SIMPLIS	Inductor/transformer energy storage, ripple, basic sizing
Magnetics synthesis	RidleyWorks, SIMPLIS MDM, Frenetic	Core, turns, wire, loss balance, thermal limits
Physics validation	COMSOL or similar FEA	Field distribution, hot spots, leakage, advanced EMI
Final sign‑off	SIMPLIS, SPICE tools plus FEA if needed	Margin to ratings, lifetime, worst‑case behavior

Technical highlights relevant to passive components

What the tools actually decide

While the tools in this series vary widely in scope, for passive components they influence a common set of decisions:

• Core shape, material, and size for inductors and transformers.
• Number of turns, wire gauge, and layering to balance copper loss, leakage, and manufacturability.
• Capacitance, voltage rating, ESR/ESL, and package for DC‑link and output capacitors.
• Resistor ratings and networks used for sensing, damping, and snubbing.

Workflow‑centric tools like SIMPLIS with MDM, and cloud platforms like Frenetic, are particularly focused on embedding these decisions into a systematic process, rather than treating magnetics as isolated spreadsheets.

Accuracy versus speed trade‑offs

Simulation environments vary significantly in their modeling depth and runtime:

• SPICE‑class tools provide high fidelity for device‑level behavior but may require careful tuning for convergence in complex switching circuits.
• Power‑electronics‑focused simulators aim for robust and fast convergence with simplified device models, ideal for exploring topologies and doing sensitivity analysis on passive values.
• Magnetics design suites and FEA tools emphasize accurate core and copper loss estimation, field distribution, and thermal behavior, at the cost of higher setup complexity and runtime.

In practice, design teams often accept lower fidelity in early architectural studies and parametric sweeps, moving to higher‑fidelity magnetics or FEA tools only once a promising design has been identified.

AI agents for magnetic and passive design

Most of the value in AI for power electronics sits in how well the agent understands magnetics and passives, not just topologies. Beyond sizing a transformer or inductor from simple rules of thumb, an AI agent can search a large design space of core shapes, materials, and winding strategies while respecting EMI, thermal limits, and manufacturability. For capacitors and resistors, it can do something similar by balancing ripple, lifetime, and cost across thousands of catalogue parts instead of a short human‑curated shortlist.

In practice this means: you describe power level, topology, cooling constraints, isolation requirements, and mechanical envelope in text; the agent decomposes this into a series of design problems and calls specialized calculators and databases. Instead of manually iterating through spreadsheet tabs and manufacturer apps, you get a first feasible magnetics and passives set in minutes, then refine with your engineering judgement.

Example: Frenetic AI in the power‑magnetics loop

Frenetic AI is a good example of where this is already happening in practice. Their agent can propose DC/DC converter designs, generate custom magnetics, and directly output LTspice and KiCad projects for further analysis. From a passives perspective, the interesting piece is that the topology selection, magnetic core choice, and initial winding design are handled by the system, while the engineer focuses on constraints and verification.

Once a candidate transformer or inductor is defined, the same workflow can be extended to suggest suitable capacitors (bulk, decoupling, snubbers) and resistors (sense, damping, dividers) based on voltage stress, ripple current, and lifetime models. The long‑term direction is clear: one agent orchestrates magnetic design, spice model generation, layout‑relevant parasitic estimation, and preliminary BOM creation, all driven from a textual spec.

AI‑assisted selection of catalogue passives

Finding OTS passives is often more time‑consuming than running the simulations themselves. An AI “BOM agent” can take electrical requirements (voltage, current, frequency, lifetime) and mechanical constraints, then search distributors, in‑house ERP, and manufacturer datasheets to propose consistent, sourceable part sets. This is especially useful when you want multi‑sourcing across vendors and packages, or when you must align with company‑specific approved vendor lists.

For magnetics, the same approach can filter standard cores and bobbins before you consider custom parts. For capacitors, it can automatically enforce derating rules per technology (MLCC, electrolytic, film, tantalum), check ripple ratings, and pre‑screen for reliability constraints such as AEC‑Q200. For resistors, it can combine power rating, pulse capability and temperature coefficient rather than treating them as separate filters in a parametric search.

Custom magnetics and manufacturability constraints

Custom magnetics are where today’s design tools often stop and spreadsheets begin. Customization can happen at many levels: core shape and material, gap strategy, winding style (solid, foil, litz), and even hybrid constructions. The limiting factor is not imagination but the ability to calculate parasitics, losses, and manufacturability quickly enough across this design space.

Agentic systems can help by chaining together multiple physics and loss models through APIs, exploring trade‑offs between copper loss, core loss, leakage inductance, and cost. You might specify maximum hot‑spot temperature, allowed interwinding capacitance, and leakage window, and let the agent drive FEM, 1D loss models and cost estimation until it converges on a manufacturable design. The result is not a “black box transformer,” but a parameterized design you can inspect, tweak, and hand over to a magnetics supplier with traceability.

System‑level design: integrating passives into AI workflows

Tools like Celus aim at the system‑design level, from requirements to complete circuit proposals. For passives, this means that instead of dropping default resistor–capacitor values around IC reference designs, the system can reason about control‑loop stability, EMI filters, surge handling, and safety margins automatically. The output is not just a schematic but a set of justifications: why a given EMI filter topology was chosen, why a particular capacitor technology was selected, or how much lifetime margin you have at ambient plus ripple self‑heating.

As these platforms mature, passives will no longer be “filled in later” but will be co‑designed with magnetics, semiconductors, and layout from the first AI‑generated draft. That should reduce late‑stage surprises such as overheating input capacitors or inductors that oscillate with stray capacitances.

PCB layout, parasitics and EMI with AI ECAD

PCB‑centric tools such as Flux AI, JITX and Quilter target the routing and layout side of the workflow. They already use AI to place and route components, check design rules, and optimize cost and area. The next step, very relevant for passives and magnetics, is learning to treat the PCB as part of the magnetic and capacitive structure rather than just a connection medium.

Given a power stage plus magnetics, an AI layout engine can minimize loop areas, control dv/dt and di/dt paths, and place decoupling capacitors to reduce ringing and EMI. With access to FEM or fast field‑solvers, it can estimate parasitic inductances and capacitances of traces, vias and planes and feed them back into updated spice models. This closes the loop between schematic‑level magnetics and passives design and their real‑world behaviour on the PCB.

Hardware validation and test guidance

In the near future the same agent that designed the converter can also supports the lab validation. For passives and magnetics, this is particularly valuable because many field issues show up first as “small” anomalies: slightly elevated temperature, unexpected noise, or marginal waveforms. An AI test assistant can suggest measurement setups, interpret oscilloscope and thermal‑camera captures, and flag patterns that indicate saturation, poor damping, or insufficient derating.

In a more advanced setup, the agent knows the full design history, including how the passive and magnetic values were chosen, and can propose targeted design changes when tests reveal problems. For example, it might recommend a different capacitor technology, a modified snubber network, or a winding rearrangement to fix a specific EMI notch rather than a generic “increase filter size” suggestion.

What this means for passive‑components engineers

If the trajectory sketched above holds, a single engineer with strong domain expertise plus good AI tooling will indeed do the work of a small team. Routine tasks such as initial sizing, catalogue searches, and documentation will be mostly automated, while human effort moves toward defining constraints, validating edge cases, and negotiating trade‑offs with other disciplines.

For engineers working on passives and magnetics, the opportunity is to encode your heuristics and constraints into these AI‑driven workflows instead of fighting them. That can mean building internal calculators and APIs that agents can call, curating high‑quality component data, or contributing to open ecosystems around magnetic and passive models. The teams that combine deep component‑level understanding with agentic automation will set the pace for future power‑electronics design.

Conclusion

Selecting and designing passive components for modern power converters now depends as much on the chosen software toolchain as on the underlying topologies and materials. General‑purpose and power‑electronics‑focused simulators establish realistic electrical stress and operating points, while specialized magnetics tools translate those requirements into manufacturable inductors and transformers.

Manufacturer parametric selectors and online calculators remain useful at the front end of the process, but they must be complemented by integrated simulation and, where necessary, physics‑based FEA to achieve robust, production‑ready designs.

For both engineers and purchasers, the most effective strategy is to build a coherent workflow that links these tool classes, so that every passive component decision—from first sizing to final derating—is traceable, verifiable, and aligned with project cost and reliability targets.

FAQ: Power Electronics Tools for Passives and Magnetics

Source

This article is based on a two‑part technical series by Dr. Chema Molina reviewing current power‑electronics tools for simulation, component selection, and magnetics design and how they fit into a modern converter design workflow.
