CDEIR10D48ME is a low profile, high current power Inductor with dust core shielded. It is ideally used in High current POL converters, DC/DC converters in distributed power systems.
ย Key Features:
- Size:ย 11.0 x 10.3 x H5.0 mm (max.)
- Product Weight: 2.7g (ref.)
- Operating Temperature Range:ย -40ยฐCย ~ +125ยฐC
(Including coil’s self temperature rise) - Storage Temperature Range:ย -40ยฐC ~ +125ยฐC
Applications:
High current POL converters, high current power supplies, DC/DC converters in distributed power systems
Parts List:
| Part Name | Inductance [within](ยตH)ย โป1 |
D.C.R at 20โ Max.(Typ.)ย (mฮฉ) | Saturation Current(A) (at 20โ)ย โป2 |
Temperature Rise Currrent (A)ย โป3 |
| CDEIR10D48MENP-4R7MC | 4.7ยฑ20% | 11.0(9.0) | 15.0 | 9.0 |
โป1 Measuring frequency Inductance at 100KHz, 1.0V
โป2 Saturation current: This indicates the value of D.C. current when the inductance becomes 20% lower than its initial value. (Ta=20โ).
โป3 Temperature rise current: The actual value of D.C. current when the temperature of coil becomes โณT=40โ.(Ta=20โ).
Production Stage:
In mass production
