Bourns Magnetics product line is pleased to introduce the AEC-Q200 compliant, automotive grade 1kV model SM91574AL BMS signal transformer.
This single channel functional insulation transformer includes common mode chokes for noise rejection in BMS applications.
The Model SM91574AL was developed for use with TI’s BQ79718.
This BMS transformer offers a working voltage of 1000 VDC and Hi-PoT isolation voltage up to 3000 VAC with an extended operating temperature range of -40 to +125 °C.
Features
- Pin auto-termination
- Up to 1000 VDC working voltage and Hi-Pot up to 3000 VAC
- Supports serial daisy chain / IsoSPI communication
- Developed for use with TI’s BQ79718
- Expanded temperature range: -40 to +125 °C
- RoHS compliant and halogen free
- AEC-Q200 compliant automotive grade
Applications
- Battery Management Systems
- Energy Storage Systems
Source:
Bourns
