Kyocera Introducing SAW Filters for Implantable Medical and AED Applications

Kyocera introduces SAW filters dedicated for use in implantable pacemakers and automated external defibrillators (AEDs).

To contribute to people’s daily health improvement and to help create a better society, Kyocera is developing components that advance the technology and capabilities of medical devices.

The new SAW filter products SF16-0403C5UBPx and SF16-0403C5UUPx are mainly used in implantable pacemakers and automated external defibrillators (AEDs), contributing to the evolution of medical devices.

Features

1. Unique structure (solder sealing ring: below) provides high reliability suitable for implants. Sealed and shock-resistant.
2. No.1 market share worldwide for 403MHz CSP (Chip Size Package) SAW filters for the MICS Medical Implant Communications Systems market.
3. Low loss
4. High attenuation
5. Dimensions: 1.6×1.4×0.4mm
6. Output 200Ω – balanced (SF16-0403C5UBPx) and unbalanced (SF16-0403C5UUPx) versions

Structure
