Coilcraft Power inductors with specialised terminations

27.10.2017
Reading Time: 1 min read
A A

Source: Dataweek news

11 October 2017, Coilcraft added two new products to its line of high-current, moulded power inductors, both offering unique termination options.

RelatedPosts

Würth Elektronik Releases High-Frequency Connectors for Antenna Cables

Murata Releases First High-Frequency XBAR Filter for Next-Gen Networks

Vishay NTC Immersion Thermistor Delivers Fast Response in Liquid Cooled Automotive Systems

The XTL7030 series features side metal terminations for automated optical inspection (AOI) of the component during the solder reflow process. It offers inductance values from 10 to 47 µH and provides current handling up to 5,3 A and very low AC + DC power losses for greater efficiency.

XTL7030 inductors measure just 7,1 mm square, with a maximum height of 3,2 mm. They feature RoHS compliant tin-silver over copper terminations and are halogen free. They are also qualified to AEC-Q200 Grade 1 standards (-40°C to +125°C ambient), making them suitable for automotive and other harsh-environment applications.

The XAR7030 series marks the first time raised inductors are available as standard, off-the-shelf products. They measure 8,5 mm square, with terminals that elevate the inductor body 1,5 mm from the printed circuit board surface. The unique off-the-board construction allows standard power management IC packages (e.g., QFN/VQFN) to be mounted beneath the inductor in a 3D packaging arrangement, reducing overall board space.

The XAR7030 is available with inductance values ranging from 0,16 to 10 µH, and offers DCR as low as 1,26 m. It features RoHS-compliant matte tin over nickel over phosphor bronze terminations and is also halogen free.

The composite construction of both products results in soft saturation characteristics, allowing them to withstand high current spikes. They exhibit no thermal ageing issues, and their construction also minimises audible buzzing.
