Vishay TNPW Series Thin Film Flat Chip Resistors | Video Tech Specs

15.6.2020
Reading Time: 1 min read
A A

Vishay TNPW Series Thin Film Flat Chip Resistors

Vishay’s TNPW series of chip resistors are trimmed down to ±0.1% tolerance with a meandering laser that eliminates hot spots for excellent long-term stability, and they’re offered with low TCR options to provide a consistent resistance under varying conditions. Vishay also uses a specialized passivation method for enhanced moisture resistivity and silver palladium internal terminations to prevent sulfur-based corrosion.

Vishay TNPW series resistors are offered in case sizes from 0201 to 1210 and with values from 1 ohm to 3 megaohms, and they’re AEC-Q200 qualified.

RelatedPosts

NIC Components Extends SMD High Voltage MLCC Offering

Stackpole Offers RoHS Compliant Lead-Free Thick Film Chip Resistors

Smiths Interconnect’s SMD Power Resistors with Heat Sink Qualified to Space Flights

  • Excellent long-term stability: ±0.05% drift after 1000 hours, ±0.1% drift after 8000 hours
  • TCR options: ±10ppm/°C, ±15ppm/°C, ±25ppm/°C, ±50ppm/°C
  • Sulfur resistance verified according to ASTM B 809
  • Superior moisture resistivity (85°C/85% RH)
  • New space saving 0201 package size
  • AEC-Q200 qualified

Related

Source: Vishay Intertechnology, TTI, All About Circuits
