Bourns Releases New Generation of Automotive Isolation Power Transformers

5.6.2024
Reading Time: 3 mins read
A A

Bourns unveils second-generation of its AEC-Q200 compliant, automotive grade high creepage/clearance distance isolation power transformers.

Model HCT8xxxxEAL Series Transformers are a high reliability, compact solution offering reinforced insulation up to 800 V and basic insulation up to 1000V.

RelatedPosts

Bourns Releases High Power High Ripple Chokes

Bourns Unveils High Reliability Compact Micro Encoders

Bourns Released Rugged, High-Power TO-247 Thick Film Resistor

These AEC-Q200 compliant, automotive-grade push-pull high voltage isolation power transformers offer a high reliability, compact solution that delivers reinforced insulation for working voltages up to 800 V and basic insulation for working voltages up to 1000 V.

By providing a separate reinforced insulating layer that protects against dangerous voltages, the Model HCT8xxxEAL Series helps designers better meet their safety and reliability goals compared to competitive isolation transformers that are only capable of functional insulation. The advanced features in this series make these transformers ideal for use in isolation applications in automotive Battery Management Systems (BMS), RS-485, CAN interface, digital input module and RS-323 isolation designs.

Bourns’ latest high voltage isolation transformers feature 3.3 or 5 V input to various output voltages per turn (up to 350 mA in various turns ratio configurations). Manufactured in a fully automated line that maximizes device quality and reliability, the Model HCT8xxxxxEAL Series is designed with Bourns’ unique over-molding technology that uses cost-effective FIW wire to deliver superior efficiency.

In addition to the reinforced isolation with 8 mm minimum clearance/creepage distance that delivers an elevated level of isolation from high voltage hazards, this series is compliant with IEC 62368-1 and IEC 61558-1 standards. Bourns developed these new transformers for isolation power supplies that employ Texas Instruments Model SN6501 and SN6505 transformer drivers. Available now, the Bourns® HCT8xxxxEAL Series is RoHS compliant.

Features

  • Overmolding technology with fully automated manufacturing
  • Complies with IEC 62368-1 and IEC 61558-1 standards
  • Reinforced insulation for working voltage of 800 Vrms and basic insulation for 1000 Vrms
  • Designed for isolation power supplies using TI Model SN6501 and SN6505
  • AEC-Q200 compliant, automotive grade
  • RoHS and REACH compliant

Applications

  • Automotive BMS
  • RS-485
  • CAN interface
  • Digital input modules
  • RS-323 isolation

Related

Source: Bourns
