Coilcraft High Voltage Molded Power Inductors Video Datasheet

21.4.2020
Reading Time: 1 min read
A A

Coilcraft high voltage molded power inductors enable greater power conversion efficiency in high-frequency applications with large ripple currents. The XEL4010V, 4020V, and 4030V series inductors are rated for 120-volt operation, 50% higher than standard parts, while low DCR and ultra-low AC losses improve efficiency in high switching frequency power converters.

All series have a 4.0 x 4.0 mm footprint, with heights from 1.2 to 3.2 mm. Their composite construction provides soft saturation characteristics, minimizes audible buzzing, and provides magnetic shielding, enabling their use in high-density designs or near sensitive circuits.

RelatedPosts

NIC Components Extends SMD High Voltage MLCC Offering

Stackpole Offers RoHS Compliant Lead-Free Thick Film Chip Resistors

Smiths Interconnect’s SMD Power Resistors with Heat Sink Qualified to Space Flights

Inductors are available from 92 nH to 6.8 µH, with current ratings up to 33.2A. The inductors don’t exhibit thermal aging and are AEC-Q200 Grade 1 qualified, making them ideal for automotive applications and other harsh environments.

  • Operating voltage: 0 – 120 V, 50% higher than standard inductors
  • Low DCR and low AC losses maximize efficiency in 2 to 5 MHz switching converters
  • DImensions: 4.0 x 4.0 mm footprint, 1.2 – 3.2 mm height
  • Composite construction: soft saturation, minimized audible buzzing, magnetic shielding
  • Inductance values: 92 nH to 6.8 µH (current ratings up to 33.2A)
  • AEC-Q200 Grade 1 qualified (−40°C to +125°C)

Related

Source: Coilcraft
