Common-mode chokes are widely used noise suppression components for a variety of applications. For a better understanding of the main datasheet parameters and charts Würth Elektronik explains them in detail in this webinar.
The agenda include explanations of common-mode choke:
- core materials
- core shapes
- common-mode choke parameters:
- main inductance
- leakage inductance
- DC resistance
- rated current
- rated voltage
- insulation test voltage
- scattering parameters
- insertion loss
- impedance
The video will also demonstrate how to simulate common-mode chokes using software tools like Qucs and LTspice®.
