In Chapter I/1.2.1 Connector Housing, the four major functions of a connector housing were identified as: Electrical insulation: All of...

As per the IPC-A-610D, a compliant solder joint must fill at least 75% of the free volume between the pin...

As noted previously, the THR reflow practice is basically identical to the SMT reflow practice. As such, it can be...

Whenever possible, it is desirable to use automatic pick and place technologies to insert the connectors into the PCB PTH....

Basically, pins can be round or any rectangular shape, as shown in Figure 2.95. The pin geometry plays an important...

The solder paste is applied to the PCB and a subsequent squeegee pass is used to push the paste into...

The solder paste volume on the PCB surface will be determined by the thickness and area of the stencil opening....

The screen printing process is particularly important because it determines the amount of solder paste that will be applied to...

The basic requirement of a THR manufacturing process is to ensure compatibility with the existing SMT manufacturing process, typical stages...

In a lead-free world, the most common finish is tin because of its very good wettability properties. However, tin can...
