Murata Develops the World’s First 0.1uF Multilayer Ceramic Capacitor in 008004 size

5.12.2019
Reading Time: 2 mins read
A A

Murata Manufacturing Co., Ltd. has developed the GRM011R60J104M, the world’s first multi-layer ceramic capacitor*1 to feature a maximum capacitance of 0.1µF 6.3V X5R in 008004 inch size (0.25×0.125mm). Mass production of this new product is scheduled to begin in 2020.

As smartphones supporting 5G become more widespread and devices such as wearable devices become increasingly multifunctional and more compact, the demand for smaller and higher density electronic circuitry is growing. Among the components employed in this circuitry, multi-layer ceramic capacitors are essential for electronic devices and are used for a wide range of applications such as in smartphones and wearable devices. As the high end smartphones are equipped with around 800 to 1,000 capacitors, there is a considerable need for such components to be made even more compact.

RelatedPosts

Military and Aerospace Interconnect Design: Key Trade-offs

Samsung Introduces 630V X7T Molded Frame Capacitor for Automotive

Exxelia Presents Disc Capacitors and Integrated Magnetics for Space

By using our original ceramic and electrode material atomization and homogenization technology, Murata has achieved a mounting surface area approximately 50% smaller and a volume approximately 80% smaller than that of our conventional product (01005 inch size)*2 with a capacitance of 0.1µF. Moreover, the new product has a capacity of around 10 times that of the same-sized product (008004 inch size)*3 initially mass-produced by the Company.

In future, Murata will continue to conduct research and development into ceramics and high-precision, microscopic layering technology for electrode materials, expand our lineup to meet the needs of the market, and contribute to the further miniaturization and greater functionality of electronic devices.

*1 According to research by the Company. As of November 30, 2019.
*2 Comparison with the existing 01005 inch size (0.4×0.2mm) product with a capacitance of 0.1µF
*3 Comparison with the 008004 inch size product with a capacitance of 0.01µF initially mass-produced by the Company (Press release on May 7, 2014 “World’s First! Murata Launches Mass Production of World’s Smallest 0201-size (0.25 x 0.125 mm) MonolithicCeramic Capacitors from April 2014”)

Main specifications

Product nameGRM011R60J104M
Size (L×W×T)0.25mm×0.125mm×0.125mm
Capacitance0.1µF (=100nF)
Capacitance tolerance±20%
Usage temperature range-55°C to 85°C
Temperature characteristicsX5R characteristics (EIA)
Rated voltage6.3Vdc

Related

Source: Murata
