Murata Releases 0504 Chip Common Mode Choke Coils

17.12.2024
Reading Time: 2 mins read
A A

Murata Manufacturing Co., Ltd. has newly commercialized noise suppression products, 0504 inch size chip common mode choke coils “DLM11CN_HH2 Series which are suitable for use with high-speed differential interfaces used in automobiles such as LVDS*1, SerDes*2, USB, and HDMI.

Mass production of this product began in December 2024.

RelatedPosts

Murata Releases In-vehicle Compact Crystal in 2016 Size

Murata Announces Mass Manufacturing of World’s First 0402 47µF MLCC

Murata Releases First High-Frequency XBAR Filter for Next-Gen Networks

In the automobile market, the development of the advanced driver-assistance system (ADAS) and autonomous driving (AD) has led to an increase in the range and number of sensing devices such as vehicle periphery sensing cameras and LiDAR*3, as well as display devices such as around view monitors, headup displays, smart rearview mirrors, and LCD speedometers.

LVDS and SerDes are used for the transmission of image data in these devices. Multiple USB ports are equipped in each vehicle seat as interface for connecting smartphones and computers, which calls for smaller products.

Common mode noise suppression is a key issue for these differential interfaces, and therefore a smaller SMD chip common mode choke coil is in demand for high-speed signals. Drawing on proprietary lamination technique, Murata developed the 0504 inch size―smaller than the conventional 0805 inch size―as a solution to this demand.

Product nameDLM11CN500HH2DLM11CN900HH2DLM11CN201HH2
Common mode
Impedance
(at 100 MHz)
45Ω±25%90Ω±25%200Ω±25%
Rated current100 mA80 mA60 mA
Operating temperature range‐55 to +125℃
OthersAEC-Q200*4 compliant
  • *1 LVDS (Low Voltage Differential Signaling): An interface used for LCD panels.
  • *2 SerDes (Serializer/Deserializer): Circuits that convert between the serial and parallel signals in each direction.
  • *3 LiDAR (Light Detection and Ranging): A system that detects obstacles around the vehicle by emitting lasers.
  • *4 AEC-Q200: One of the standards defined by the AEC (Automotive Electronics Council).
