Samsung Electro-Mechanics announces the world’s first ultra-small multilayer ceramic capacitor (MLCC), featuring a capacitance of 22nF at a rated voltage of 100V in the compact 0402 inch (1.00 × 0.50mm) size, X7S (-55 to 125℃). Samples and technical support are now available for partners and clients.
Rapid growth in 48V vehicle systems, and convergence of power-electronic platforms—combining on-board chargers (OBC), inverters, DC-DC converters, and wireless power transfer (WPT)—is driving demand for high-voltage, miniaturized, and reliable passive components.
Stable 100V operation is crucial in automotive safety and powertrain circuits. Samsung Electro-Mechanics’ 0402 MLCC ceramic capacitor establishes new market standards for miniaturization without compromising electrical or environmental performance.
Samsung Electro-Mechanics‘ new 100V ultra-small MLCC solution meets these demands, ensuring stable performance in critical automotive circuits. This advancement strengthens our position in the automotive electronics market and provides innovative technology for future trends.
Specifications
| Model | Size (inch/mm) | Capacitance | Rated Voltage | TCC | Sample Availability |
|---|---|---|---|---|---|
| CL05Y223KC56PN# | 0402 / 1005 | 22nF | 100Vdc | X7S | Available |
Features
- Ultra-small size optimizes PCB footprint for miniaturized automotive modules
- High voltage rating (100V) enhances reliability in demanding environments
- Stable performance from -55°C to +125°C (X7S)
- Approved for key automotive applications: power electronics, charging, and conversion circuits
CL05Y223KC56PN# is designed specifically for use in EV, hybrid, and cutting-edge vehicle electronics, supporting new generations of inverters, OBC, DC-DC converters, and WPT systems.
