Panasonic expand its long-life surface mount type series to its product line of OS-CON Conductive Polymer-Aluminum-Solid Capacitors.
Available with a rated voltage of 2.5VDC, 6.3VDC and 16VDC, SVPT products benefit from huge capacitance values (100µF up to 560µF) and low ESR characteristics (15-24mΩ max.).
The components are able to withstand now operations at temperature +105°C for up to 20.000 hours making them ideal for use in demanding applications such as power circuits in servers, base stations, as well as Smart Meters or other power management systems.
As all OS-CON range capacitors, SVPT series devices feature excellent noise reduction capability and frequency characteristics, a long life span and their ESR values have little change even at low temperatures since the electrolyte is solid.The components are RoHS compliant and halogen free.
The first three types within the new series include:
- 100µF 24mΩ
- 330 µF 6.3V 15mΩ
- 560µF 2.5V 16mΩ
