Temperature influence of the saturation current for an inductor

4.12.2019
1 min read
0 0
0
SHARES
1
VIEWS

Lorandt explains the influence of the temperature to the saturation current of a power inductor. First he uses the permeability vs. temperature chart, and explains the correlation to the initial inductance value. Furthermore, the difference from sintered materials like nickel zinc and manganese zinc are shown, but also from power materials and iron alloys use in WE-MAPI and WE-LHMI are shown.

Source: Würth Elektronik
